PVC insulated shielded wire

PVC Insulated Shielded Wire is in accordance with GB5023-1997 and JB8734-1998;GB9330-88 or IEC227-1979 ModelDescriptionReference Standards227IEC74RVVYPPVC sheathed, shielded, oil-resistantGB5023-1997IEC60227-1997RVPcopper conductor, PVC insulated, shielded, flexible wiresJB8734-1998RVP-90copper conductor, heat resistant (up to 90), PVC insulated, shielded, flexible wiresRVVPcopper conductor, PVC insulated, shielded, PVC, sheathed, flexibleKVVPcopper conductor, PVC insulated, PVC sheathed, braided, shielded, control cableGB9330-88 or IEC227-1979KVVP2copper conductor, PVC insulated, PVC sheathed, copper-tape shielded, control cableKVVRPcopper conductor, PVC insulated, PVC sheathed, braided shielded, flexible, control cableFor 227IEC74RVVYP, RVP, RVP-90, RVVP; Application: PVC Insulated Shielded Wire&cable is suitable for communication field in the outdoor circuit and shielded circuit for electrical meters, electronic equipment ,broadcasting and automation devices for rated voltage 450/750v and below. 2. Operating characteristics: a. Max long-time working temperature of conductor should not exceed 70°C. b. Being laid in the air, the ambient temperature should not be less than 0 . c. The bending radius should not be less than 4 times outer diameter of the cable, if the outer diameter of the cable is less than 25mm, and it should not be less than 6 times outer diameter of the cable if the outer diameter of the cable is 25mm, and above. For KVVP, KVVP2, KVVRP In accordance with GB9330-88 or IEC227-1979, this product is applied for power signal controlling, monitoring loop and protection circuit, for rated A/C voltage 450/750V. Operating characteristics: 1 The long-time permissible operating temperature is 70;The ambient temperature under installation should not go below 0. 2a. for non-armoured cable and flexible shielded cable, the bending radius should not be less than 6 times the outer diameter; b. for armoured or copper-tape shielded cable, the bending radius should not be less than 12 times the outer diameter;
